SmartRail is a versatile Remote I/O option for Horner OCS – with popularity options including CsCAN and Ethernet. In this Hands-on session we’ll connect and demonstrate the NEW SmartRail I/O Ethernet Base with support for both Ethernet/IP and Modbus TCP. Re-designed for 2022, this component provides an easy way to add Ethernet-based I/O to your OCS All-in-one Controller.
To view the Cscape demo used in this video, click here: https://hornerautomation.com/wp-content/uploads/2023/01/SmartRail-Test-ETX250.zip
For more information, please visit: https://hornerautomation.com/product/smartrail-bases/
For Cscape information, or to download a FREE copy, visit: https://hornerautomation.com/cscape-software/
For other Horner Live Q & A Events – check out our LIVE playlist – https://www.youtube.com/playlist?list=PLo8pKsXu4vWWHCDSyrGbONEi24EiyAQdL
Table of Contents:
00:00 – Intro
01:13 – Chat with Casey
03:28 – Agenda
04:13 – Quick Review of SmartRail I/O
04:58 -SmartRail Connectivity
05:51 – SmartRail I/O Modules
06:49 – Available Digital I/O Modules
08:47 – Available RTD & Thermocouple Modules
09:02 – NEW SmartRail Ethernet Base vs Original
10:09 – Comparing ETX250 vs ETX200/300
12:26 – Demo – Assembling SmartRail I/O
14:24 – NEW SmartRail Ethernet Base
16:28 – Demo – Configure ETX250 in Cscape
22:17 – Available Status Variable Details
23:16 – Demo – ETX250 in Action on the Bench
26:14 – Wrap-up
